| Brand Name: | kemasen |
| Model Number: | K5L-120H/0866RS |
| MOQ: | 1pc |
| Price: | Negotiable |
| Delivery Time: | 30 days |
| Payment Terms: | T/T、L/C、D/A、D/P |
Product features and advantages:
1: Anti-electrical failure, new industrial controller, patent number: ZL201920260537.X, one-button intelligent pumping Adopt three- dimensional compression molding hopper, no material accumulation, no deformation, easy to clean
2: High-rise concrete pumping, underground garage, square, factory wear-resistant ground concrete, secondary structural column fine stone concrete pouring pumping
| Pump system parameter information | |||||||||
|
name |
contents of a project |
unit |
parameter |
||||||
|
Complete performance |
Theoretical pumping distance is vertical / horizontal |
m |
60/300 |
||||||
|
Maximum concrete delivery capacity |
m3/h |
40
|
|||||||
|
Theoretical concrete conveying pressure |
Mpa |
8 |
|||||||
|
Distribution valve form |
/ |
S- Valve |
|||||||
|
Concrete cylinder specifications |
mm |
D180 |
|||||||
|
Hopper volume x feeding height |
L ×mm |
300×1200 |
|||||||
|
Discharge outlet diameter |
mm |
180 |
|||||||
|
dynamical system |
(Yuchai) Diesel engine |
Kw |
66 |
||||||
|
hydraulic pressure system |
Main oil pump power |
Mpa |
K5V140S |
||||||
|
Hydraulic system form |
Mpa/L |
Single pump hydraulic sequence unit set + inlet WINNER overflow valve + inlet PARKer Pike control valve (28 Mpa, 250L) |
|||||||
|
cooling-down method |
/ |
Air cooling radiator |
|||||||
|
Other parameters |
Maximum concrete diameter |
mm |
10-35 |
||||||
| * Note: Technical solutions can be provided according to customer needs, and different export pressure models can be selected when purchased. | |||||||||
|
| Brand Name: | kemasen |
| Model Number: | K5L-120H/0866RS |
| MOQ: | 1pc |
| Price: | Negotiable |
| Packaging Details: | Standard Export Package |
| Payment Terms: | T/T、L/C、D/A、D/P |
Product features and advantages:
1: Anti-electrical failure, new industrial controller, patent number: ZL201920260537.X, one-button intelligent pumping Adopt three- dimensional compression molding hopper, no material accumulation, no deformation, easy to clean
2: High-rise concrete pumping, underground garage, square, factory wear-resistant ground concrete, secondary structural column fine stone concrete pouring pumping
| Pump system parameter information | |||||||||
|
name |
contents of a project |
unit |
parameter |
||||||
|
Complete performance |
Theoretical pumping distance is vertical / horizontal |
m |
60/300 |
||||||
|
Maximum concrete delivery capacity |
m3/h |
40
|
|||||||
|
Theoretical concrete conveying pressure |
Mpa |
8 |
|||||||
|
Distribution valve form |
/ |
S- Valve |
|||||||
|
Concrete cylinder specifications |
mm |
D180 |
|||||||
|
Hopper volume x feeding height |
L ×mm |
300×1200 |
|||||||
|
Discharge outlet diameter |
mm |
180 |
|||||||
|
dynamical system |
(Yuchai) Diesel engine |
Kw |
66 |
||||||
|
hydraulic pressure system |
Main oil pump power |
Mpa |
K5V140S |
||||||
|
Hydraulic system form |
Mpa/L |
Single pump hydraulic sequence unit set + inlet WINNER overflow valve + inlet PARKer Pike control valve (28 Mpa, 250L) |
|||||||
|
cooling-down method |
/ |
Air cooling radiator |
|||||||
|
Other parameters |
Maximum concrete diameter |
mm |
10-35 |
||||||
| * Note: Technical solutions can be provided according to customer needs, and different export pressure models can be selected when purchased. | |||||||||
